| Brand Name: | CMC |
| MOQ: | 1 set |
| Price: | according to the machine requirement |
| Payment Terms: | Down payment 30% T/T, 70% T/T before shipping |
| Supply Ability: | According requirement |
Advantages
It adopts the most advanced Fiber Laser Source, Gear-rack Transmission from Atlanta Germany, Reducer from
Stowe Bell Germany, Servo Motor from Yaskawa Japan, PA8000 Top-level CNC Control System, Linear Guide
Rail from HIWIN Taiwan.
Equipment Introduction
SFC system is a cost-effective investment including Fiber Laser Source, Water Cooling System, Automatic
Laser Head, Cutting Flatbed, Control System, Exhaust System etc.
Structure
Overall fixed workpiece&Gantry-type structure, 3-axis movement controlling system, X&Y axis achieves flat
surface movement, Z axis tracks material surface with floating up&down movement.
Clean Robots
NS Series
NX Series
NV Series
TT Series
TX Series
WIDE WORKING RANGE
The next-generation designs of clean robots feature an independent drive on all axes, which significantly increases the usable work area with minimal dead-space and greater flexibility. The TT and TX series are designed with telescopic bases for applications requiring large vertical reach.
HANDLING OPTIONS AVAILABLE
A wide variety of handling options are available across the clean robot series. Both 300 mm and next-generation 450 mm wafer handling robots are available, along with dual-gripping technology that allows a single robot base to handle two wafers. Models are also available with an additional axis for handling wafers at both horizontal and vertical angles.
CLEANROOM SPECIFICATION
Strict design and assembly standards allow this series of arms to conform with a range of ISO cleanroom standards, as well as adhering to the SEMI F47 and SEMI S2 standards for voltage and safety requirements.
PROGRAMMING FLEXIBILITY
Clean series robot controllers offer superior programming flexibility with manual, semi-automatic, and full-automatic teaching methods. Ethernet communication port as a standard enables a high level of communication with various equipment in a facility.
